Induction Top And Oven, 4 Zones
Article no: 589845TCV400350Model no: MCIMEAJ8DM
Experience premium performance with the Thermaline 90 modular cooking range, designed for fast, efficient, and hygienic professional cooking. The 4‑zone induction top delivers immediate full power with minimal heat dispersion, while the smooth glass‑ceramic surface ensures effortless cleaning. Pans glide easily across zones, and each area features overheat protection and dedicated control lights.
The robust oven reaches up to 300 °C, offering two GN 2/1 levels, a ribbed enamelled base, grilling capability, and precise electronic temperature control with manual humidity regulation. A 40 mm insulated door ensures excellent heat retention.
Built for durability, the unit features a 2 mm AISI 304 top, stainless‑steel internal frame, ergonomic metal knobs with hygienic silicon grips, and IPX5 water‑resistant construction. The THERMODUL connection system creates a seamless worktop for maximum hygiene and easy servicing. A large tempered‑glass digital display and standby mode provide intuitive operation and energy savings.
The robust oven reaches up to 300 °C, offering two GN 2/1 levels, a ribbed enamelled base, grilling capability, and precise electronic temperature control with manual humidity regulation. A 40 mm insulated door ensures excellent heat retention.
Built for durability, the unit features a 2 mm AISI 304 top, stainless‑steel internal frame, ergonomic metal knobs with hygienic silicon grips, and IPX5 water‑resistant construction. The THERMODUL connection system creates a seamless worktop for maximum hygiene and easy servicing. A large tempered‑glass digital display and standby mode provide intuitive operation and energy savings.
- Front handrail is available as an optional extra
- Marine feet and rolling racks included
Voltage
400V 3Ph ~50Hz
Loading
25 kW
Dimensions
1000 x 700 x 900
Technical Product Specifications
Certifications & regulations
IP Class
X5
Dimensions & weight
Width, net (mm)
1000
Depth, net (mm)
700
Height, net (mm)
900
Weight, net (kg)
197
Weight, gross (kg)
225
Volume, net (m3)
0.63
Volume, gross (m3)
0.82
Electric
Voltage (V)
400
Phase
3
Has neutral
No
Frequency (Hz)
50
Connection Cable, length (m)
0
Connector side
Bottom
Loading (kW)
25
Max Amps in Phase (A)
10.8
Plug type
None
General data
Country of origin
Switzerland
Variant Model Number
MCIMEAJ8DM
Included in delivery description
- 1 of Grid, chromium-plated, for ovens 2/1 GN
- 2 x S/S Side Panels 912512
- 1 x end rail kit 913202
- 1 x end rail kit 913203
- Rolling racks
- 200 mm high marine feet
- 2 x S/S Side Panels 912512
- 1 x end rail kit 913202
- 1 x end rail kit 913203
- Rolling racks
- 200 mm high marine feet
Variants
| Model | Name | Power Supply | |||
|---|---|---|---|---|---|
589845TC | MCIMEAJ8DM | Induction Top and Oven, 4 Zone | 440V 3Ph ~50/60Hz | ||
589845TCV400350 | MCIMEAJ8DM | Induction Top And Oven, 4 Zones | 400V 3Ph ~50Hz |
